Hydraulic cylinder as an important executive element in the hydraulic system, its inlet and outlet diameter and the selection of thread parameters for the stability of the entire system and work efficiency is very important. These parameters not only affect the fluid flow rate and pressure distribution, but also directly related to the cylinder and other parts of the hydraulic system connection and reliability.

The size of the inlet and outlet diameters directly determines the flow capacity of the fluid in the cylinder. Larger inlet and outlet diameters can increase the flow rate and flow of the fluid, thus ensuring that the hydraulic cylinder can respond quickly and achieve the required thrust during operation. However, too large an inlet and outlet diameter can also increase its size and weight, posing challenges to the overall layout and installation of the system. Therefore, when selecting the inlet and outlet diameters, it is necessary to consider its thrust requirements, system layout, and installation space.

The selection of thread parameters is important for the connection between the cylinder and other parts of the hydraulic system. Suitable thread parameters can ensure that the connection between the cylinder inlet and outlet and other components is tight and secure, avoiding oil leakage and system failure. Common thread types include internal and external threads, the size and specification of which should be selected according to system requirements. In addition, attention needs to be paid to the machining accuracy and surface quality of the threads to ensure the stability and long-term nature of the connection.

In summary, the inlet and outlet diameters and thread parameters of hydraulic cylinders are important factors affecting system performance. When selecting these parameters, it is necessary to comprehensively consider factors such as the thrust demand of the cylinder, the system layout, the installation space and the connection method with other components. Through reasonable selection and matching, it can ensure that the hydraulic cylinder plays a good performance in the hydraulic system and improve the efficiency and stability of the whole system.
